APsystems Accessories

APsystems offers a range of accessories to ensure proper installation and function of our microinverter systems. See your installation manual or contact our technical support department to determine the proper, certified APsystems accessories for your application.

APsystems YC500i

1
2
3
4
5
6
7
8
1

ac-bus-t-conn-cap-300x197

YC500i AC Bus

  • Applicable models：YC500i
  • Provides the junction of the inverter’s AC output side and grid connection
  • CSA/TUV certified
  • 2,5mm2 (TC-ER 3C/14AWG)
  • Drop Length：2M
2

yc500-ac-connector-unlock-tool-copy-300x197

1 Standalone YC500 AC Branch Cable

  • Applicable models：YC500I
  • Provides one microinverter’s AC cable to do the grid connection
  • 14AWG or 18AWG,  (TC-ER 3C)
3

yc500-ac-bus-t-conn-cap-300x197

YC500i AC Bus T-CONN Cap

  • Applicable models：YC500i
  • Protects the unused T-CONN on the AC Bus
4

yc500-ac-bus-end-cap-300x197

YC500i AC Bus End Cap

  • Applicable models：YC500i
  • Provides water proof for the end of AC Bus
5

unlock-300x197

YC500i AC Connector Unlock Tool

  • Applicable models：YC500i
  • Unlocks the inverter and AC Bus
6

AC module mounting plate

Allows the attachment of the YC500 microinverter onto a PV module frame without drilling.

7

25A AC Female & Male Connectors (Single-phase :3-wire)

Provides a quick and easy way to complete AC cable extensions and can replace a junction box.

8

aps-mc-4-male-plug

DC Male Connector Cap

  • Applicable models：YC500I , YC600 & YC1000-3
  • Protects the unused DC Female Connector

DC Female Connector Cap

  • Applicable models：YC500I , YC600 & YC1000-3
  • Protects the unused DC Female Connector

APsystems YC1000-3

1
2
3
4
1

yc1000-ac-bus-300x197

YC1000-3 Trunk Cable

Part No. Cable-2 (for 2 meter trunk cable for portrait array orientation)

Part No. Cable-4 (for 4 meter trunk cable for landscape array orientation)

YC1000-3 Trunk cable. The 14 AWG cable is sold with two part unique part numbers – with connectors spaced at 2 meters or 4 meters. The varied spacing allows the YC1000-3, Model 208 or 480, to be installed in landscape or portrait.

2

aps-terminal-cap

YC1000-3 AC Bus T-CONN Cap

  • Applicable models：YC1000-3
  • Protects the unused T-CONN on the AC Bus
3

aps-yc1000endcap

AC Bus End Cap – YC1000-3

Part No. AC Bus End Cap – YC1000-3

Terminates the bare wire on the Trunk Cable for the YC1000-3.

  • Weather proof termination cap for the bare wire end of the YC1000-3 Trunk Cable.
  • Insert five bare wires into five cable clamps to terminate
  • 41 mm size
4

2 m DC extension cable

Provide a 2 meters DC extension cable to the YC1000 to speed up and ease the  installation process on multiple roofs lay-outs.

APsystems YC600

1
2
3
4
5
1

YC600 AC Bus

  • Provides the junction of the inverter’s AC output side and grid connection
  • CSA/TUV certified
  • 2,5mm2 (12AWG)，U-1000-RO2V ( TC-ER)
  • Drop Length：2M
2

YC600 AC Connector Unlock Tool

  • Unlocks the inverter and AC Bus
3

YC600AC Bus Y-CONN Cap

  • Protects the unused Y-CONN on the AC Bus
4

YC600 AC Bus End Cap

  • Applicable models：YC500i & YC600
  • Provides water proof for the end of AC Bus
5

Pair of MC4 Caps (Male and Female)

Part No. MC4 Caps

  • Female cap is used to cover and protect unused MC-4 male connector coming from second pair of YC600 DC connections.
  • Male plug is used to protect unused MC-4 female connector in same application.
